Sudarshan Column Pipes are specially designed to extract underground water from bore-wells with the use of submersible motor pumps. These pipes are also known as Drop or Riser pipes. Sudarshan Column Pipes are manufactured using double-stage bi-axial technology and threaded using CNC machines to ensure high precision. They are capable of handling internal hydrostatic pressure caused by the pump, tensile load of the pipe-water column, the pump and motor, and the impact of water hammering.
Through our continuous R&D activities, Sudarshan has developed HEAVY SERIES for deep submersible boreholes. Sudarshan HEAVY SERIES Pipes come with long couplers and wider square threads to take higher working pressure and load. Stringent online quality checks and rigorous testing in our laboratory have made Sudarshan Column Pipe the ‘Farmers’ First Choice’.
Sudarshan Pipes (PVC Division) pioneer in manufacturing Innovative Products – Sudarshan Column Pipes since 2003, used with submersible pumps to draw water from 200 feet to 2100 feet deep borehole/borewell, replacing GI Pipes/ HDPE Pipes due to their better mechanical properties and performance. Sudarshan Column Pipes are successfully installed in more than 12,00,000 boreholes/borewells Pan India and Abroad – 15+ Countries incl Gulf, Africa, and Europe. Sudarshan Column Pipes – 1” to 6” (32mm to 160 mm) come in a wide range – Eco, Deluxe, Super Deluxe, Heavy, Super Heavy for various depths and pump delivery pressure.
SIZE & CLASS
OD - Outside Dia ND - Nominal Dia |
Ultimate Breaking Load (Kgf)
|
Safe Pulling Load With Chain pulley (Kgf)
|
Safe allowable hydrostatic pressure (kg/cm2)
|
Safe Total Pump Delivery head (m)
|
---|---|---|---|---|
OD: 33 mm (1") ND: 25 mm
|
||||
Eco
|
1000
|
600
|
15
|
150
|
Deluxe
|
1200
|
800
|
21
|
210
|
Super Deluxe
|
1800
|
1200
|
30
|
300
|
Gold
|
2250
|
1500
|
35
|
350
|
OD: 42 mm (11/4") ND: 32 mm
|
||||
ECO
|
1600
|
1000
|
15
|
150
|
Deluxe
|
1800
|
1100
|
21
|
210
|
Super Deluxe
|
2500
|
1500
|
27
|
270
|
Gold
|
3000
|
1800
|
35
|
350
|
Heavy
|
3100
|
1875
|
35
|
350
|
Super Heavy
|
3600
|
2200
|
40
|
400
|
Ultra Heavy
|
4100
|
2500
|
45
|
450
|
OD: 48 mm (11/2") ND: 40 mm
|
||||
ECO
|
2000
|
1200
|
15
|
150
|
Deluxe
|
2500
|
1500
|
21
|
210
|
Super Deluxe
|
3000
|
1800
|
27
|
270
|
Gold
|
4000
|
2400
|
35
|
350
|
Heavy
|
4100
|
2450
|
35
|
350
|
Super Heavy
|
4500
|
2700
|
40
|
400
|
Ultra Heavy
|
5000
|
3000
|
45
|
450
|
OD: 60 mm (2") ND: 50 mm
|
||||
ECO
|
2400
|
1600
|
9
|
90
|
Deluxe
|
3000
|
2100
|
13
|
130
|
Deluxe Plus
|
3400
|
2400
|
17
|
170
|
Super Deluxe
|
3850
|
2700
|
21
|
210
|
Gold
|
5000
|
3500
|
27
|
270
|
Heavy
|
5200
|
3600
|
27
|
270
|
Super Heavy
|
5700
|
4000
|
35
|
350
|
Ultra Heavy
|
6600
|
4600
|
40
|
400
|
OD: 75 mm (2½ ̎) ND: 65 mm
|
||||
Deluxe
|
3400
|
2000
|
9
|
90
|
Deluxe Plus
|
4000
|
2400
|
13
|
130
|
Super Deluxe
|
4700
|
2800
|
17
|
170
|
Ultra Deluxe
|
5900
|
3500
|
21
|
210
|
Gold
|
7000
|
4200
|
26
|
260
|
Medium Heavy
|
6000
|
3600
|
21
|
210
|
Heavy
|
7200
|
4320
|
27
|
270
|
Super Heavy
|
9000
|
5400
|
35
|
350
|
Ultra Heavy
|
10400
|
6240
|
40
|
400
|
OD: 88 mm (3 ̎) ND: 80 mm
|
||||
Deluxe
|
4800
|
2800
|
9
|
90
|
Super Deluxe
|
7000
|
4200
|
17
|
170
|
Ultra Deluxe
|
8200
|
4900
|
21
|
210
|
Gold
|
9600
|
5650
|
26
|
260
|
Medium Heavy
|
8400
|
5020
|
21
|
210
|
Heavy
|
9600
|
5760
|
27
|
270
|
Super Heavy
|
12400
|
35
|
7440
|
350
|
OD: 113 mm (4 ̎) ND: 100 mm
|
||||
Deluxe
|
6650
|
4000
|
9
|
90
|
Super Deluxe
|
10000
|
6000
|
17
|
170
|
Medium Heavy
|
13000
|
7700
|
21
|
210
|
Heavy
|
16000
|
9600
|
27
|
270
|
Super Heavy
|
20600
|
12360
|
35
|
350
|
OD: 140 mm (5 ̎) ND: 125 mm
|
||||
Super Deluxe
|
16400
|
9800
|
17
|
170
|
Medium Heavy
|
20800
|
12400
|
21
|
210
|
Heavy
|
24000
|
14600
|
27
|
270
|
Super Heavy
|
30500
|
18600
|
35
|
350
|
OD: 165 mm (6 ̎) ND: 150 mm
|
||||
Heavy
|
40000
|
24000
|
27
|
270
|
